Strength
As key features, we highlight the high quality steel material used, the lightweight construction design and the optimized internal cooling.
The AM20 milling head represents a new milestone for the manufacture of cutting tools.
The AM2' milling system starts from diameter 63 mm with PCD or solid carbide cartridges.
As key features, we highlight the high quality steel material used, the optimized internal cooling oriented to the flute.
The AM30 drilling system combines three materials joined together, solid carbide body, steel printed head and solid PCD tablet.
As key features, we highlight the high quality steel material used, the optimized internal cooling and the modular custruction.
The AM40 gives the great feature to build as modular system depending on the diameters required.
Characterized by its hardness and abrasion resistance, H13 tool steel is a hot work steel with exceptional hot hardness, resistance to thermal fatigue cracking, and stability in heat treatment—making it an ideal metal for both hot work and cold work tooling applications.
*Extrusion dies
*Injection molds
*Hot forging dies
*inserts and cavities
One of the most versatile steels, 4140 steel is characterized by its toughness, high fatigue strength, and abrasion and impact resistance, making it a great all-purpose steel for industrial applications.
*Jigs and fixtures
*Automotive
*Bolts/Nuts
*Gears
17-4 PH stainless steel is a precipitation hardening steel used in a wide range of industrial applications including those with mildly corrosive environments and high-strength requirements.
*Manufacturing machinery
*Chemical processing
*Pump components
*Valving
Characterized by its corrosion resistance and performance at both high and low temperatures, 316L stainless steel is a fully austenitic steel ideal for harsh environments.
*Food processing
*Laboratory equipment
*Medical devices
*Jewelry
Characterized by its electrical and thermal conductivity and ductility, Copper is ideal for electrical equipment, plumbing, and heat transfer applications.
*Consumer and industrial electronics
*Heat exchangers
*Antennas
*Inductors
Nylon mixed with chopped carbon fiber offers a high-strength thermoplastic with excellent heat resistance, surface finish, and chemical resistance. Heat Deflection Temperature, Onyx has an HDT of 145° C (293° F and has a flexural strength of 81 MPa (11.7 ksi).
*Robotic arms
*End use parts
*Fixtures
*Inspection Fixtures
Carbon Fiber is a unique, ultra-high-strength Continuous Fiber — when laid into a Composite Base material like Onyx, it can yield parts as strong as 6061-T6 Aluminum. It’s extremely stiff and strong, and can be automatically laid down in a wide variety of geometries.
*Robotic arms
*End use parts
*Fixtures
*Inspection Fixtures
Fiberglass is entry-level Continuous Fiber —a material capable of yielding parts 10x stronger than ABS when laid into a Composite Base material like Onyx. Fiberglass is the flagship material of the printing machine, providing a more affordable alternative to Carbon Fiber.
*Robotic arms
*End use parts
*Fixtures
*Inspection Fixtures
Nylon is an unfilled thermoplastic. It’s a non-abrasive material that is great for ergonomic surfaces and workholding for pieces that are easily marred. It can be painted or dyed.
*Robotic arms
*End use parts
*Fixtures
*Inspection Fixtures
Onyx FR is a flame-resistant variant of Onyx designed for use in applications where parts must be non-flammable. The material earned a UL Blue Card, and is considered V-0 (self extinguishing) at thicknesses greater than or equal to 3mm. It can be reinforced with any Continuous Fiber and is compatible with industrial composite 3D printers.
*Weld fixturing
*Aerospace brackets
*Laser fixtures
*Electrical fixtures
High Strength High Temperature (HSHT) Fiberglass is defined by two characteristics: high strength (nearly equal to 6061-T6 Aluminum) and strength in high temperatures. Though not as stiff as Continuous Carbon Fiber, Onyx parts reinforced with HSHT are strong at both low and high temperatures. As a result, HSHT reinforcement is best used for parts in high-temperature environments like molds, autoclaves, and others.
*Polymer moulds
*Prototype moulds
*High temp. Fixtures
*High temp. prototypes
Kevlar is a specialized Continuous Fiber known for its energy absorption and extreme toughness. When laid into Onyx or another Composite Base material, it yields extremely impact-resistant parts that are nearly immune to catastrophic failure (fracture). It’s perfect for use in parts that are in demanding environments or are subject to repetitive loading.
*End-of-Arm Tooling
*Stanchions, Cradles,...
*Delrin Parts
*Wear Stops
